Vibro roller types are differentiated based on the number of drums, drum surface shape, and tool size. Each type has different compaction characteristics so it needs to be adapted to soil conditions, material, area, and construction project needs.
In general, Vibro roller is used to compact the soil, pasir, gravel, and granular materials by combining drum pressure and vibration. The use of the right tools helps produce a denser and more stable soil layer as the basis for road development, foundation, industry, and other infrastructure.
For projects that require soil compaction, PT Perkasa Sarana Utama (PSU) provides vibro roller rental services 10 ton with a choice of smooth drum and padfoot drum. Both types can be considered according to the material characteristics and compaction targets in the field. Information on the types of vibro rollers and their complete specifications will be discussed in this article.
What are the Types of Vibro Rollers?
Type vibro roller commonly known in construction work include single drum rollers, double drum roller, combination roller, smooth drum roller, padfoot drum roller, as well as baby rollers. These groupings use different bases, from drum configuration to tool size.
The following is a summary of the types of vibro rollers and their uses.
| Vibro Roller Type | Characteristics | Main Uses |
| Single Drum Roller | One steel drum and rubber wheel | Compaction of subgrade and aggregate |
| Double Drum Roller | Two steel drums | Compaction and leveling of road surfaces |
| Combination Roller | Steel drum and rubber wheels | Compaction with specific end result requirements |
| Smooth Drum Roller | Smooth steel drum surface | Granular soil compaction and surface leveling |
| Padfoot Drum Roller | The drum has a protrusion | Cohesive soil compaction, like clay |
| Baby Roller | Smaller size and weight | Compaction in a limited area |
Selection of tools is not enough just based on type. Material conditions, the thickness of the compacted layer, target density, and machine specifications also need to be taken into account so that the work runs effectively.
1. Types of Vibro Rollers Based on Number of Drums
One way to identify the type of vibro roller is to look at the configuration of the compactor drum or cylinder used. The number of drums affects the operating characteristics and type of work that can be handled.
Single Drum Vibro Roller
Single drum vibro roller has one steel drum on the front and a rubber wheel on the back. This configuration makes it suitable for subgrade compaction work (subgrade) and aggregate materials in the construction area.
This tool is often used in land preparation, road construction, and foundation work that requires a stable base layer. The effectiveness of compaction still depends on the type of material, soil conditions, as well as vibration settings and work layer thickness.
Double Drum Vibro Roller
Double drum vibro roller has two steel drums, one each at the front and back. This type is also known as a tandem roller and is widely used for compacting and leveling road surfaces.
Both drums help produce an even compaction trajectory. On paving work, This tool can be used to compact the asphalt layer according to the stages and specifications of the work.
Combination Roller
Combination rollers combine steel drums with pneumatic rubber wheels. This configuration is designed for work that requires the compaction characteristics of the steel drum as well as the function of the rubber wheels at certain stages.
Its use can be considered in road pavement projects, depending on the material and end result requirements. However, the combination of these components does not automatically make it suitable for all types of work, so that the equipment specifications and compaction methods still need to be checked.
2. Types of Vibro Rollers Based on Drum Surface
Apart from the number of drums, The shape of the drum surface is an important factor in choosing a vibro roller. Two commonly used types are smooth drums and padfoot drums. The difference in surface shape between the two affects how compaction forces are applied to the material.
Smooth Drum Vibro Roller
Smooth drum vibro roller has a smooth steel drum surface without protrusions. This shape helps to apply pressure evenly to the material being traversed, making it suitable for compacting granular soil, such as sand and gravel, as well as certain surface leveling work.
The smooth drum type can be used in land preparation work, compaction of the aggregate layer, and road projects according to their construction stages. Its use needs to be adjusted to the characteristics of the material so that the target density can be achieved.
For projects that require tools with these characteristics, PSU provides Smooth Drum Vibro Roller 10 Tons, Diesel Powered. This unit can be an option for compaction work that requires a smooth drum surface.
Product and rental information can be viewed via katalog Smooth Drum Vibro Roller PSU or page Smooth Drum Vibro Roller 10 Tons, Diesel Powered.
Padfoot Drum Vibro Roller
The vibro roller drum padfoot has protrusions on the surface of the drum that help provide concentrated pressure on the material. This type is generally used for cohesive soil compaction, Like the land of the land (clay), according to the conditions and material specifications in the field.
The protrusions on the drum help the compaction process in soil layers that require better penetration compared to using a smooth drum. This tool can be considered for soil compaction work on road projects, dam, and land preparation.
PSU provides Padfoot Drum Vibro Roller 10 Tons, Diesel Powered for soil compaction needs. Before renting, ensure that the soil characteristics and project density targets match the capabilities of the selected unit.
You can see the selection of units through catalog vibro roller PSU or access the page Padfoot Drum Vibro Roller 10 Tons, Diesel Powered.
3. Types of Vibro Rollers Based on Size
The size and weight of the tool also influences the choice of vibro roller. Tools with greater weight are generally used for large areas, while small rollers can help work in locations with limited space.
Standard Vibro Roller
Standard vibro roller is a large compacting tool used for construction work covering large areas. Units in weight classes are approx 10 tons can be considered for soil and aggregate compaction work on road projects and land preparation.
The use of tools must follow the unit specifications and project conditions. Machine weight alone is not enough to determine compaction results due to soil type, spread thickness, number of passes, and vibration settings also influence the final result.
For project needs that require a class roller 10 ton, PSU provides a choice of smooth drum and padfoot drum. These two types can be selected based on the characteristics of the material to be compacted.
Baby Roller atau Mini Vibratory Roller
A baby roller is a compacting tool that is smaller than a standard roller. Its compact size means this tool can be considered for work in limited areas, like a pedestrian path, park area, certain pavement works, and locations that are difficult to reach for large tools.
The capacity and compaction ability is different from large vibro rollers. Because of that, Baby rollers are more suitable for jobs that meet the limits of the tool's capabilities, not a direct replacement for large class rollers on the entire project.
Before determining the choice, check the width of the work area, type of material, density requirements, and equipment mobilization access to the project location.
Read too : Vibro Roller Recommendations 10 The best tons for various projects
How to Choose the Right Type of Vibro Roller?
Choosing the right vibro roller helps compaction work run more efficiently and supports the quality of the construction layer. The following things need to be considered before determining which unit to use.
1. Get to know the type of material
Material is the main consideration in drum selection. Smooth drums are generally suitable for granular materials such as sand and gravel, while padfoot drums are more often used on cohesive soils such as clay.
When the soil condition is a mixture of several materials, consult compaction requirements with technical personnel so that the type of equipment used is appropriate to field conditions.
2. Adjust to the Project Area Size
Projects with large areas may require large rollers to make compaction work more efficiently. On the contrary, limited areas need to consider the dimensions of the tool, maneuvering space, and entry to the location.
Apart from the area, Also take into account the condition of the surface, Land slope, as well as the space available for tool movement.
3. Check Density Target
Each project may have different density requirements. Factors such as material type, layer thickness, vibration frequency, and the number of passes needs to follow the technical specifications of the job.
Because of that, Don't make a choice based solely on the weight of the tool. Ensure that the units used are capable of supporting the compaction targets set in the project planning.
4. Consider Rental Efficiency
If the tool requirement is only for a certain stage in the project, Renting a vibro roller can be an alternative to buying your own unit. Planning the rental duration and usage schedule helps optimize machine costs.
Also make sure the costs are included in the offer, mobilization provisions, operator needs, and unit availability before work begins.
Read too : Difference between Tandem Roller and Vibro Roller
Rent a Vibro Roller for your Project at PSU
Choosing the appropriate type of vibro roller is an important part of soil compaction and infrastructure construction work. Smooth drums and padfoot drums have different characteristics so their selection needs to consider the type of material, field conditions, and target density.
PT Perkasa Sarana Utama (PSU) provides vibro roller rental services 10 tonnes with a choice of smooth drum and padfoot drum to support construction project needs. Available choice of vibro roller units from brands like Sakai, Bell, and STA according to the PSU product catalog.
With experience of more than 19 years in the field of heavy equipment rental and logistics, PSU is ready to help you determine tool choices based on project needs. Consult the type of work, location, and duration of use so that the PSU team can help provide appropriate offers.
Need a vibro roller rental for your construction project? Immediately contact the PT Perkasa Sarana Utama team to get the best offer and check unit availability this week.
